Thetibolt

M6x18 TAPERED Wide Washer Single Titanium Bolt

M6x18 TAPERED Wide Washer Single Titanium Bolt

$10.00 CAD
$10.00 CAD
Sale Sold out
Shipping calculated at checkout.
  • Part number: T0029
  • Name: M6x18 TAPERED Wide Washer
  • HEAD TYPE: Tapered
  • HEAD TOOL INTERFACE: HEX5
  • SIZE: M6
  • THREAD PITCH: 1.0
  • SHAFT LENGTH (mm): 0mm
  • THREAD LENGTH (mm): 18
  • HEAD DIAMETER: 10mm with 12mm washer
  • HEAD HEIGHT: 4mm + 1mm oversized washer d=12mm
  • Weight: 3.15 g
  • USE: Post Mount Caliper Bolts
  • Max Torque: 12Nm
  • Installation advice: Link to installation guide
  • Disclaimer: Warning! Choking Hazard, Small Parts, Product appearance may vary slightly. Use at your own risk!
  • Finish: Polished, PVD coating

Bolts are sold as single units

Warning

  • Use Anti-Seize compound and a torque wrench for a correct installation

Features

  • High quality titanium
  • PVD coated
  • Corrosion free
  • Lighter and stronger than steel bolts

Shipping

Worldwide Shipping Available

View full details

The Solution

Oversized Washer System

Standard bolts concentrate stress on a small area. Our direct mount bolt system with oversized precision washers improves load distribution and protects the delicate aluminum caliper interface.

Load Distribution

Increasing the contact surface spreads clamping force across the mounting tab.

Surface Protection

The washer prevents the titanium bolt head from digging into the softer aluminum interface.

Alignment Stability

Greater surface friction helps prevent micro-movement under braking loads.

Why Titanium?

Brake caliper bolts live in a harsh environment.

  • Corrosion resistance
  • Consistent torque feel
  • Premium strength
  • Highly reusable
Titanium feature
